Pioneer A-Series 6 x 9-inch 2-Way 460W Component Speakers (Pair) - TS-A693CH
Ask Bolt?
Similar Products In Stock (5 items)
Pioneer 6" x 9" 2-Way Component System (Pair)
Contains 1 Reviews
1
Your Price:
$152.99
Regular Price:
Comp. Value: $229.99
Pioneer A-Series 6 x 9-inch 2-Way 450W Component Speakers (Pair)
Your Price:
$113.62
Regular Price:
Comp. Value: $189.99
Shop Pioneer
Abt Model: TSA693CH
UPC: 884938509466
Ship to
Call for availability
Your Price:
$149.99
Regular Price:
Comp. Value: $189.99
Email
Notify me when this item is available
Ask Bolt?
Pioneer TS-A693CH A-Series 6 x 9-inch 2-Way 460W Component Speakers (Pair)
The Pioneer TS-A693CH 6" x 9" speakers component system can handle power up to 460 W Max (105 W RMS). The woofer cone is made of Aramid Fiber reinforced polypropylene for rigidity, low-frequency responsiveness, and weather resistance. The woofer comes with adjustable woofer brackets to use in all kinds of makes and models. Install the separate 20mm tweeters with the included tweeter mounts in an area high in your vehicle for better sound.
Features
- CarSoundFit
Pioneer’s Car Sound Fit app is actually a car sound simulator for experiencing in-car sound with your own smartphone. Hear the difference between original car speakers and different Pioneer audio upgrades: convince yourself of the level of quality Pioneer can offer for your vehicle. For a virtual listening demonstration of these and many other Pioneer car speakers, download the free Pioneer CarSoundFit app. - Installation 6" x 9"Multi-Fit
Included with the component system are 6 x 9 multi-fit installation adapters that expand flexibility and improve acoustic performance. The included Pioneer multi-fit installation adapters can be easily modified to fit a variety of different applications by simply breaking off or cutting off the easy to remove tabs until the shape and mounting points match the original speaker. Replacing your factory speakers has never been easier. - Open & Smooth
Pioneer’s OPEN & SMOOTH sound concept provides a seamless and smooth transition between the midrange and tweeter drivers and delivers uniform off-axis frequency response optimized for automotive applications where one or more speakers are often aimed away from the listeners’ ears. - A Series
The Pioneer A-Series speaker sound design purposely matches the subwoofer and full-range loudspeakers to provide seamless and smooth sound characteristics with dynamic, high-impact bass that lets you hear and feel the music. Pioneer’s OPEN & SMOOTH sound concept provides a seamless and smooth transition between the midrange and tweeter drivers and delivers uniform off-axis frequency response optimized for automotive applications where one or more speakers are often aimed away from the listeners’ ears. The A-Series lineup expands flexibility and improves acoustic performance. The integrated inline crossover network allows for increased installation flexibility without the need of an outboard module. Included with the Pioneer A-Series, are multi-fit installation adapters and tweeter mounts (when applicable).
California customers:
General
Color
Black
Type
6 x 9 Inch Car Speakers
Size (in)
6 x 9
Series
A-Series
Design
2-Way
Speaker Type
Component
Peak Power Handling (W)
460
RMS Power Handling (W)
105
Integrated Amplifier
No
Frequency Response
30 Hz - 58 kHz
Impedance (Ohms)
4
Sensitivity (dB)
92
Voice Coil Type
Glass Imide
Surround Material
Elastic Polymer
Enclosed
No
Magnet
Ferrite - Woofer
Tweeter Composition
Polyetherimide
Tweeter Design
Hard Dome
Woofer Composition
Ferrite
Approximate Dimensions
Cutout Diameter (in)
8.75 x 6
Mount Depth (in)
2.88
Package Size HxWxL (in)
4 x 12 x 16
Warranty Information
Parts Warranty
1 Year Limited
Labor Warranty
1 Year Limited
Approximate Weight
Package Weight (lbs)
6
Guides
Frequently Asked Questions
-
These speakers handle a peak power of 460 watts and have an RMS power handling of 105 watts, ensuring they can deliver powerful and clear audio performance ideal for most car audio systems.
-
The woofer cone is made from aramid fiber reinforced injection molded polypropylene, offering rigidity, low-frequency responsiveness, and weather resistance. The tweeter uses a 20mm polyetherimide hard dome for crisp and clear high-frequency sound.
-
The speakers provide a wide frequency response from 30 Hz to 58 kHz, covering deep bass to high treble sounds for a full and immersive listening experience in your vehicle.
-
Yes, they come with multi-fit installation adapters that can be customized by breaking or cutting tabs to fit various mounting points, making installation straightforward across many different vehicle models.
-
These speakers include a one-year limited warranty on parts as well as labor, offering protection and peace of mind against manufacturing defects.
