Pioneer A-Series 6 x 9-inch 5-Way 700W Coaxial Speakers (Pair) - TS-A6991F
Pioneer TS-A6991F A-Series 6 x 9-inch 5-Way 700W Coaxial Speakers (Pair)
A Series
The Pioneer A-Series speaker sound design purposely matches the subwoofer and full-range loudspeakers to provide seamless and smooth sound characteristics with dynamic, high-impact bass that lets you hear and feel the music. Pioneer’s OPEN & SMOOTH sound concept provides a seamless and smooth transition between the midrange and tweeter drivers and delivers uniform off-axis frequency response optimized for automotive applications where one or more speakers are often aimed away from the listeners’ ears. The A-Series lineup expands flexibility and improves acoustic performance. The integrated inline crossover network allows for increased installation flexibility without the need of an outboard module. Included with the Pioneer A-Series, are multi-fit installation adapters and tweeter mounts (when applicable).
Features
- 6" x 9" 5-way coaxial speaker design
- Maximum power handling of 700 watts
- Nominal power handling of 120 watts
- Carbon and mica reinforced IMPP cone for enhanced durability and sound quality
- Includes 18mm, 11mm, and 9mm PET hard dome tweeters for precise high-frequency response
- 2-1/4" PEI film cone midrange for clear and accurate mid frequencies
- Metal basket construction for robust build
- Elastic polymer rolled surround for improved sound stability
- Ferrite magnets in both woofer and midrange for powerful magnetic force
- Glass imide voice coil material with copper wire for reliable performance
General
Approximate Dimensions
Warranty Information
Approximate Weight
Guides
Frequently Asked Questions
-
The speakers have a maximum power handling of 700 watts and a nominal (RMS) power handling of 120 watts, allowing for strong sound output with good durability under high power conditions.
-
The cone is made from carbon and mica reinforced injected molded polypropylene (IMPP), which enhances durability and sound quality. The surround is made from an elastic polymer, contributing to improved sound stability and speaker longevity.
-
These speakers provide a frequency response ranging from 29Hz to 33kHz, offering deep bass to clear high frequencies, suitable for a full-range audio experience.
-
They feature hard dome tweeters made from polyethylene terephthalate (PET) in three sizes (18mm, 11mm, and 9mm), which deliver precise and clear high-frequency sound reproduction.
-
These speakers include multi-fit installation adapters and tweeter mounts to increase installation flexibility and ease. The integrated inline crossover network eliminates the need for an external module, simplifying setup.
