Fusion Apollo Marine Zone Stereo with Built-In Wi-Fi & Ethernet - 010-01983-00

Fusion 010-01983-00 Apollo Marine Zone Stereo

The Apolo RA770 Stereo's Perfect Companion

A perfect companion to Apollo RA770, the Apollo SRX400 zone stereo combines premium design and superior sound in a compact form factor.

Key Features

• Custom audio profiles for each zone on your boat to deliver superior quality audio.
• Audio streaming with Wi-Fi technology provides high-quality audio with a faster data transfer rate.
• Experience seamless high-quality audio streaming from your music app via the AirPlay® 2 software feature.
• Enjoy the freedom of musical choice with Fusion PartyBus™-Network technology.
• Control your music from a compatible multifunction display (MFD), smart device or Garmin watch.

Features

• Designed And Engineered To True-Marine™ Standards
  Built on the True-Marine design philosophy from Fusion, the Apollo SRX400 stereo has an IPX6 and IPX7 rated water resistant front panel and has been tested to a high level of protection against salt, fog, temperature, vibration and UV.
• Modern Design And Aesthetics
  Providing uniformity across the helm, the brilliantly designed black front face blends seamlessly into black glass panels, complementing other electronics and MFDs for a tidy, uniform and elegant installation.

Superior Sound Quality In Every Environment

• Fusion Digital Signal Processing (DSP)
  A technically superior listening experience made simple, Fusion DSP optimizes the audio signal delivered to your Fusion system to produce superior sound quality at all volume levels, in every listening environment.
• Easy-To-Install DSP Profiles
  With a few clicks on your compatible smartphone, setting up your DSP profiles is made simple with the free Fusion-Link™ app. You can set up the preconfigured DSP profiles once and enjoy listening to high-quality audio customized for your ears and the environment.

The World's First Marine Stereo With Wi-Fi Technology

• Audio Streaming With Wi-Fi
  In a world-first for marine stereos, enjoy the clarity and premium quality of audio streaming with Wi-Fi technology, including the convenience of AirPlay 2 from Apple® and universal plug-and-play.
• Apollo RA770 With SRX400
  Designed with Wi-Fi onboard, the Apollo RA770 and its perfect companion SRX400 can be connected without running any wires – reducing installation time, cost and complexity.
• Over-The-Air Software Updates
  Updates are now available from your compatible smartphone or device, via the free Fusion-Link app. The Apollo Series is intelligently simple and easy to keep up to date.

Specifications

General

• Water Rating: IPX6 and IPX7 (Front panel only, when properly installed)
• Power Input: 10.8-16 VDC
• Operating Temperature Range: 32° to 122° F (0° to 50° C)
• Current (max.): 8 A
• Bluetooth Wireless Range: Up to 30 ft (10 meters)
• Wireless Frequencies/Protocols
  • Wi-Fi 2.4 GHz @ +15 dBm nominal
  • Bluetooth 2.4 GHz @ +10 dBm nominal
• Compass-Safe Distance: 3.9" (100 mm)

Remote

• Display: 2.7" optically bonded color LCD
• Built-In Amplifier: Class-D (2 Ohm stereo-stable)
• Peak Power: 140 W
• Rated Power Output (2 Ohm): 43 W rms x 2 @ 14.4 V input < 10% THD
• Rated Power Output (4 Ohm): 26 W rms x 2 @ 14.4 V input < 10% THD
• Built-In Digital Signal Processing: Yes (with preconfigured DSP profiles)
• PartyBus™-Network Capabilities: Yes (wired or wireless)
• Fusion-Link™ Control: Yes (with MFD and smartphone)
• Multi-Zone Technology: 1 Zone
• Built-In Wi-Fi: Yes
• Bluetooth Wireless Technology: Yes
• Multi-Language Interface: Bulgarian / Chinese (Simplified) / Chinese (Traditional) / Croatian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Italian / Japanese / Korean / Norwegian / Polish / Portuguese (BR) / Portuguese (PT) / Slovenian / Spanish / Swedish / Thai / Turkish
• Software Updates: Over-the-air software updates via the Fusion-Link app when connected to a wireless network router or integrated into an Apollo Series stereo network enabled with Wi-Fi technology via Ethernet.

Sources

• Sources: AM / FM / Bluetooth / Apple AirPlay 2 / UPnP

Connectivity

• Ethernet: One Ethernet port
• AM/FM Radio: One Motorola antenna connector port
• Speaker: 2 x speaker connections (1 zone amplified)
• RCA Pre-Out (Left, Right and Subwoofer: 1 zone (requires external amplification)
• Line Out: 1 (1 x L + R per zone, requires external amplification)
• Subwoofer Out: 1 x mono output (requires external amplification)
