Rockford Fosgate 6x9-Inch Saddlebag Cut-In Speaker Kit For Select 2024-Up Harley Davidson Motorcycles - HD24BL69

Rockford Fosgate HD24BL69 6x9-Inch Saddlebag Cut-In Speaker Kit For Select 2024-Up Harley Davidson Motorcycles

Loud. Clear. Relentless.

The HD24-STG3 is a high-performance, 4-speaker, 1,000-watt amplified upper fairing & saddlebag audio system.

Key Features

• Purpose-Built for 2024+ Harley-Davidson® touring motorcycles
• Element Ready™ to withstand the harsh outdoor environment like dust, water, and UV rays
• Direct saddlebag fitment for seamless upgrades in factory H-D® saddlebags
• TMS24-69 6x9” Element Ready™ saddlebag speaker for Harley-Davidson®
• Extended frequency range for increased low-end response
• Integrated motor cover prevents valuables in saddle bag from heat damage
• Precision template with ribbed design for accurate cuts using jig or air saws
• Top-loading bucket saddlebag speaker-mount with self-centering backer ring
• Top-load design keeps speaker mounted higher to preserve saddlebag space
• Top mount assembly creates a stable foundation to reduce loss of acoustic energy
• U-channel formed by mating top bucket and backer ring fight water intrusion
• Gasketed screws thread into brass inserts for increased seal and rigidity
• Grille with custom side badge finish follows compound bag-lid lines
• Speaker grille secures to bucket using four rubber O-rings for better sealing
• Watertight harness protection using Molex MX150 & Deutsch DT connections
• Patent Pending

Features

• Precision-Tuned
  Featuring long-throw woofers for high output and deep, extended low-end response, these speakers deliver powerful yet balanced sound. The large voice coil and extended frequency range enhance bass output, ensuring louder, more dynamic, and long-lasting performance.
• Performance Engineered
  Each element of these 6X9 speakers is meticulously engineered for peak performance. Now handling 40% more power than before, these speakers feature a heat-resistant motor structure and radiator ring to efficiently dissipate heat, ensuring consistent, powerful sound even under the most demanding conditions.
• Direct Fitment
  The patent-pending top-loading bucket and backer design helps to ensure smooth, precise cutting over the bag lid surface, we developed a newly designed precision-cut template with parallel ribbing. Our robust, injection-molded, tube-style gasketed saddlebag speaker mount inserts from the outside of the lid, making it possible to accommodate larger 6x9 speakers for unmatched audio performance.
• Element Ready™
  Purpose-built for the harsh motorcycle environment, this kit includes watertight, grommeted installation harnesses with OEM-style and Deutsch™ DT connectors. Designed to withstand water, dirt, UV exposure, and constant vibration, it ensures long-lasting, reliable audio performance.

Technologies

• Element Ready | Motorcycle
  All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.
• Direct Saddbag Fitment
  Direct saddle fitment for a seamless upgrade to factory H-D ABS saddlebags.
• IDHS Inductive Damping Heat Sink
  Secures directly to the top of magnet structure to improve system efficiency by reducing both distortion and back EMF (Electo-Magnetic Force) of the woofer. IDHS also utilizes fins to radiate heat and reduce voice coil temperature.
• Neodymium Motors
  Neodymium is up to 35% lighter and 65% smaller over traditional ferrite and ceramic, while having the same motor strength (Bl). This allows the speaker to fit factory locations without any modification.
• Coherent-Phase Alignment
  Precisely recessing the tweeter inside the woofer voice coil geometry ensures phase-aligned sound waves from both drivers arrive at the listener's ears simultaneously. This coherent-phase response minimizes destructive interference and phase cancellation, resulting in significantly improved stereo imaging, spatial accuracy, and vocal clarity.
• Performance Engineered
  Rooted in a legacy of American innovation, our products are proudly designed and developed in Tempe, Arizona, reflecting decades of expertise.
