How many ports support Power over Ethernet (PoE)?

This switch features 24 ports with 802.3at/af-compliant PoE+ support and a total power budget of 250 W, enabling efficient power delivery to connected devices like access points, IP cameras, and VoIP phones.

Can this switch be centrally managed through a cloud platform?

Yes, the switch integrates with the Omada Software Defined Networking (SDN) platform, allowing centralized cloud management, zero-touch provisioning, and intelligent monitoring from a single interface or via the Omada mobile app.

What network standards and protocols does it support?

The switch supports a wide range of standards including IEEE 802.3i/u/ab/z, 802.1d/s/w/q/p/x, 802.3ad/link aggregation, and advanced features like VLAN, QoS, and security protocols ensuring compatibility with various network environments.

What is the switching capacity and forwarding rate?

It offers a high switching bandwidth of 56 Gbps and a forwarding rate of 41.7 million packets per second (Mpps), ensuring smooth data flow and minimal latency in demanding network applications.

Is this switch suitable for harsh operating environments?

Yes, it operates reliably within a temperature range of 0 to 50 degrees Celsius and humidity levels of 10% to 90% non-condensing, making it suitable for typical indoor networking environments.

800-860-3577

SUMMER SAVINGS EVENT

Save throughout the site

SHOP NOW

TP-Link 28-Port Gigabit Smart Switch with 24-Port PoE+ - SG2428P

Name: TP-Link 28-Port Gigabit Smart Switch with 24-Port PoE+ - SG2428P
Brand: TP-LINK
SKU: TLSG2428P
Price: 309.99 USD
Availability: PreOrder

Ask Bolt?

TP-Link TLSG2428P 28-Port Gigabit Smart Switch with 24-Port PoE+

TL-SG2428P comes with Omada’s Software Defined Networking (SDN) platform, integrating network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network—all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.

Features

250 W PoE Budget: 24× 802.3at/af-compliant PoE+ ports with a total power supply of 250 W*.
Full Gigabit Ports: 24× gigabit PoE+ ports and 4× gigabit SFP Slots provide high-speed connections.
Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring.
Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
Static Routing: Helps route internal traffic for more efficient use of network resources.
Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
IPv6: IPv6 support with dual IPv4/IPv6 stack, MLD snooping, IPv6 neighbor discovery.

California customers:

General

Black

24× 10/100/1000 Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX), 4× Gigabit SFP Slots

Microsoft® Windows® XP, Vista™ or Windows 7, Windows 8, Windows 10, MAC® OS, NetWare®, UNIX® or Linux

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x

41.7 Mpps

56 Gbps

Yes

32.1 W (with no power device connected), 308.6 W (with 250W power device connected)

0–50 ℃ (32–122 ℉)

10–90% RH non-condensing

-40–70 ℃ (-40–158 ℉)

5–90% RH non-condensing

Yes

100-240V AC, 50/60Hz

TL-SG2428P, Power Cord, Installation Guide, Rackmount Kit, Rubber Feet
