BlackVue CM100G LTE NA LTE Connectivity Module
USB Plug-in LTE Connectivity Module for DR970X, DR900X (and Plus), DR770X, DR750X (and Plus) dashcams.
The CM100GLTE connects to your compatible BlackVue X or X Plus Series dashcam to provide easy 4G LTE connectivity. All you need is a valid Nano SIM card. The CM100GLTE connects via the USB port of your dashcam. Your BlackVue powers the module and automatically accesses the Cloud when the module is plugged in.
Note: when purchasing, make sure the CM100GLTE you choose is compatible with your mobile carrier’s network. Not compatible with DR590X Series.
Features
- LTE Connectivity Module
With DR970X/DR900X/DR900X Plus and DR770X/DR750X/DR750X Plus and DR770X Box models, you can connect the LTE Connectivity Module (CM100GLTE) which is powered by the dashcam and provides 4G LTE connectivity for your dashcam. This allows you to connect your dashcam to BlackVue Cloud and receive notifications to your phone when your parked car gets hit. It also lets you remotely see what your dashcam sees in real time. Being powered by the dashcam, you do not need to worry about the CM100GLTE running out of power like you might with a self-powered router.- The CM100LTE can also enable Mobile Hotspot Function for your compatible BlackVue.
- Note to DR770X Box owners: the CM100GLTE also includes GNSS (GPS+GLONASS) so you won’t lose location/speed data when replacing the standard GNSS module included with your dash cam.
- Mobile Hotspot Function
for BlackVue DR970X, DR770X and “X Plus” models
With Mobile Hotspot Function, your compatible BlackVue can now turn into a mobile internet router for up to five devices* concurrently. This means you and your passengers can now use your BlackVue’s internet on your laptop, portable game console, tablet or mobile. To connect to the BlackVue, simply open your devices’ Wi-Fi menu, select the BlackVue and enter the dashcam’s Wi-Fi password.- Supported models: BlackVue DR970X, DR770X and X Plus Series models. Requires an active data plan.
- (*) To ensure the reliability of critical BlackVue Cloud features (Live Event Upload, Push notifications, Remote Live View, etc.), connecting a BlackVue to another BlackVue is not possible at the moment.
California customers:
General
Color
Black
Type
LTE Connectivity Module
Incident Detection (G-Sensor)
No
Voice Control
No
Compatibility
BlackVue DR970X, DR900X (and Plus), DR770X, DR750X (and Plus)
App-Controlled
Yes
GPS Enabled
Yes
Power Source
Dashcam
Wi-Fi
No
LTE Capable
Yes
Operating Temperature
-35°C ~ +75°C
Power Consumption
Idle Mode : 30mA / Traffic Mode : 620mA @ Max. Power (23dBm)
Power Supply
USB Harness Cable : 3.0m, Typical Supply Voltage : 5.0V / 1A, Supply Input Voltage : 3.3V ~ 5.5V / Max. Current : 2A
Warranty Information
Parts Warranty
1 Year
Labor Warranty
1 Year
Approximate Weight
Unit Weight (lbs.)
0.24
Package Weight (lbs)
1
Approximate Dimensions
Height (in)
0.39
Width (in)
3.54
Depth (in)
2.36
Package Size HxWxL (in)
3 x 6 x 9
Similar Products (5 items)
Frequently Asked Questions
-
Yes, a Nano SIM card is required to operate the LTE Connectivity Module. It is not included with the module and must be obtained separately. Ensure the SIM card is compatible with your mobile carrier's network.
-
The module connects via the USB port of a compatible BlackVue dashcam. It is powered directly by the dashcam, eliminating the need for an external power source and ensuring continuous operation.
-
Enabling LTE connectivity allows real-time remote viewing, event notifications, and automatic cloud uploads. It also offers a mobile hotspot function for compatible models, allowing up to five devices to share internet access through the dashcam.
-
The module is designed to operate reliably in temperatures ranging from minus 35 degrees Celsius to plus 75 degrees Celsius, making it suitable for various environmental conditions.
-
No, it is specifically compatible with BlackVue DR970X, DR900X (and Plus), DR770X, and DR750X (and Plus) dashcam models. It is not compatible with the DR590X Series.
