Kanto Pro Series Full Motion Wall Mount For Flat Panel TVs 55" - 120" - PMX800
Kanto PMX800 Pro Series Full Motion Wall Mount For Flat Panel TVs 55" - 120"
Don’t let the size of your TV dictate where you put it. Capable of supporting panels up to 120”, PMX800 adjustable wall mount can be horizontally offset 11” in either direction to dial in the lateral placement of your display. An oversized 900×600 VESA interface improves compatibility with extra-large touch screens and provides flexibility for vertical positioning. With 31.3” of extension, this full motion wall mount gives you all the swivel needed to get the perfect viewing angle. Its low-profile design allows your TV to sit 2.6” from the wall when fully retracted and features all-metal cable management and lag bolt covers to stand the test of time. Toolless tilt rounds off PMX800’s extensive feature set allowing for on-the-fly adjustments.
Features
- Supports Extra Large Displays
Whether you’re designing the ultimate home theatre, or installing interactive touch panels, PMX800’s 200 lb. weight capacity ensures compatibility with displays of any size. - Horizontal Offset
Even if your studs are in a suboptimal position, you can still nail your TVs placement with 22 total inches of horizontal offset. Oversized TV brackets provide flexibility to achieve the perfect height. - Low Profile Design
The unique design of this articulating wall mount allows your TV to sit 2.6 inches from the wall when fully pushed in. - Impressive Extension
Easily reach over fireplaces or out of recessed locations with 31.3” (79.5 cm) of extension. - Toolless Tilt Mechanism
A toolless cam lever tilt mechanism allows for on-the-fly adjustments. Tilt your screen forward up to 12 degrees or backwards 3 degrees - Aluminum Covers
Maintain a clean, finished appearance while hiding any sign of installation with the aluminum wall plate covers on this fully featured TV wall mount. - Swivels Up to 180 Degrees
Achieve the best viewing angle regardless of where you’re sitting by swivelling your TV up to 90 degrees left or right, depending on screen size. - Designed to Last
PMX800’s cable management system is made of metal to stand up to regular use and reduce potential service calls. - Convenient Bolt Pack
Because every installation is unique, this pro series full motion wall mount is carefully packaged with all the hardware you could need. Choose between a variety of bolt diameters and lengths, as well as several spacers to perfectly fit your TV. Lag bolts and concrete anchors are also provided for both wood studs and concrete walls.
General
Warranty Information
Approximate Weight
Approximate Dimensions
Similar Products (5 items)
Frequently Asked Questions
-
This wall mount supports TVs ranging from 55 to 120 inches in size and can hold a maximum weight of up to 200 pounds, making it suitable for most large flat panel displays.
-
The mount extends up to 31.3 inches from the wall, allowing you to position your TV out from recessed areas or over obstacles like fireplaces for optimal viewing angles.
-
It offers a toolless tilt adjustment range of +12 to -3 degrees for easy on-the-fly positioning along with a swivel capability of up to 90 degrees in either direction depending on the screen size, ensuring the best viewing angle.
-
Yes, the package includes all necessary mounting hardware for both wood stud and concrete installations, including a paper template for pilot holes, spacers, lag bolts, concrete anchors, and an installation manual.
-
The mount comes with an integrated cable management system made of metal to keep cables organized and protected, maintaining a clean and professional appearance around your installation.
