BlackVue DR770X-1CH FHD 1080P GPS WiFi Dash Cam With 64GB SD Card - DR770X-1CH II

BlackVue DR770X-1CH II FHD 1080P GPS WiFi Dash Cam With 64GB SD Card

The DR770X-1CH is the latest upgrade over the previous DR750X series and packs a new CPU and image processor and boasts a new CPU and image processor for better waulity footage. With upgraded sensors and 60 FPS at Full HD, the DR770X is capable of capturing an unprecedented level of detail, day or night.

The DR770X also comes loaded with all the additional features you'd expect from a top tier dash cam, such as parking surveillance mode, seamless app pairing, optional LTE cloud connectivity, built-in Wi-Fi, GPS, and Bluetooth, as well as the option to add a secondary rear, or interior camera at any point in the future.

If that's got your attention, read on below as we highlight each of the outstanding features the DR770X-1CH has to offer.

Features

• Double The Frames, Double The Details
  Recording video at 60 frames per second offers significant benefits. With the DR770X, you can capture ultra-smooth videos that preserve every detail, even in fast-paced action scenes. As a result, the camera is better equipped to capture crucial details like license plates, even when objects are in motion, as motion blur is greatly reduced compared to 30fps.
• Add A Secondary Camera
  The DR770X-1CH offers expandability from one recording "channel" to two, just like its predecessors in the DR750X and DR900X series. This latest model includes an extra input port for a secondary camera, giving you the option to use it as a front-only dash cam or to add a rear-facing, interior-facing, or waterproof TRUCK camera at a later time. With this feature, you get the best of both worlds.
  Keep in mind that you can only add one additional camera to the DR770X-1CH system, bringing the total to two camera angles. The secondary camera is not included in the base price and is entirely optional.
• GPS, Wi-Fi and Optional LTE
  • GPS
    While reviewing the footage, you can track the location of your vehicle on a map, and the video can also display your speed as an overlay. If you prefer not to have the speed displayed, you can hide it through the settings.
  • Wi-Fi
    Thanks to its Wi-Fi capabilities, you can effortlessly link your BlackVue dashcam to your smartphone or tablet. Moreover, Wi-Fi connectivity allows the camera to connect to the BlackVue Cloud via any mobile or home Wi-Fi hotspot or router. This connection grants easy access to files and settings.
  • Optional LTE
    For the optimal Cloud experience, you have the option to connect the DR770X to the BlackVue Cloud via an LTE connectivity module. The module can be connected via the USB port.
    • *SIM card not included.*
• 3 Native Parking Surveillance Modes
  The built-in accelerometer (G-sensor) in the DR770X can detect abrupt changes in speed or impacts while driving. Similarly, when parked, it can detect any visible movements around your vehicle, and these incidents are automatically labeled and saved. If a cloud connection is established, you can receive alerts and access the clips from both your computer and mobile device.
  By using the included hardwiring kit or the optional B-130X battery pack, you can hardwire the DR770X to your vehicle's fuse panel for Parking Surveillance Mode. When the ignition is turned off, the DR770X will switch to Parking Mode automatically. There are three variations of Parking Mode available:
  • Motion Detection
    Triggered when the sensor detects movement (marked “P” in the file list).
  • Impact Detection
    Detected by the accelerometer/G-sensor (marked “E” in the file list)
  • Time Lapse Mode
    Records continuously at 1FPS. 1-minute Time lapse Parking Mode video = 30 minutes real time coverage. Impacts initiate a buffered Event video.
• Optional Cloud Features
  • Live View
    Monitor your car in real time.
  • Live Event Upload
    mpact and Motion detection events are uploaded straight to the Cloud.
  • Video Backup
    Move files from the dashcam to the Cloud!
  • Remote Video Playback
    Play videos stored in the Cloud or in your dashcam anytime on your smartphone.
  • Emergency Alarm
    Get a notification whenever something happens to your car.

Specifications

• Channel: 1CH (upgradable to 2CH)
• Highlights: Full HD, Cloud, Wi-Fi, GPS, Sony Sensor, External LTE Module
• Memory: microSD card up to 256GB
• Recording Modes: Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected).
  • * For Parking mode recording, a Parking Mode Battery Pack (Power Magic Battery Pack) or a Parking Mode Hardwiring Kit (Power Magic Pro) is required.
• Parking Modes: Yes (with 3-wire hardwiring cable – included)
• Parking Mode Event Voice Notifications: Yes
• Camera: Sony STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel)
• Viewing Angle: Diagonal 139°, Horizontal 116°, Vertical 61°
• Resolution/Frame Rate: Full HD @60fps
  • * Frame rate may vary during Wi-Fi streaming.
• Video Codec: H.265 (HEVC)
• Image Quality
  • Highest (Extreme): 25 Mbps
  • Highest: 12 Mbps
  • High: 10 Mbps
  • Normal: 8 Mbps
• Format Free: Yes (Adaptive)
• Event File Overwrite Protection: Yes (up to 50)
• Video Compression Mode: MP4
• SD Card Failure Alert: Yes
• Scheduled Reboot: Yes
• Video File Extension: MP4
• Bluetooth: Built-in (V2.1+EDR/4.2)
• Wi-Fi: Built-in (802.11 b.g.n)
• Cloud Compatible: Yes
• LTE: Optional External Module
• GPS: Built-in (Dual Band: GPS, GLONASS)
• Microphone: Built-in
• Speaker (Voice Guidance): Built-in
• Impact Sensor: 3-Axis Acceleration Sensor
• LED Indicators: Recording LED, GPS LED, B/W/L (Bluetooth/Wi-Fi/LTE) LED, Front Security LED
• Button
  • Format Button
    Press and hold format button for 5 seconds, and after a beep, release the button. Then, press again and hold for 5 seconds and release the button after a beep to format the microSD card.
  • Touch Sensor
    Pressing the touch sensor triggers manual recording depending on the firmware settings.
• Backup Battery: Built-in supercapacitor
• Input Power: DC 12V-24V (DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC)
• Power Consumption
  • Normal Mode (GPS On/1CH): Avg. 240mA / 12V
  • Parking Mode (GPS Off/1CH): Avg. 190mA / 12V
    • * Actual power consumption may vary depending on use conditions and environment.
• Operation Temperature: -20°C − 80°C (-4°F − 176°F)
• Storage Temperature: -20°C − 80°C (-4°F − 176°F )
• High Temperature Cut-Off: Approx. 80°C (176°F)
• Certifications: FCC, ISED, CE, UKCA, RCM, RoHS, Telec, WEEE, KC
• Software
  • BlackVue Viewer
    • * Windows 7 or higher and Mac Yosemite OS X (10.10) or higher
  • BlackVue Web Viewer
    • * Chrome 71 or higher, Safari 13.0 or higher
• Application: BlackVue Application (Android 8.0 or higher, iOS 13.0 or higher)
• Other Features: Adaptive Format Free File Management System
